36 Chapter 5: Mono Input Channel
VeniceF
Operator Manual
EQ
Each mono input channel of the VeniceF has a four-band, swept EQ, allowing tonal
control over the input signal.
EQ section of the mono input channels
Item Description
1 Treble gain/freq control knob This dual-concentric control knob adjusts
the gain/frequency of the treble EQ:
• gain The top control knob adjusts the gain of the treble band, which is
continuously variable from -15dB to +15dB with a centre detent of 0dB.
• freq The bottom control knob adjusts the centre frequency of the treble
band, which is continuously variable from 2kHz to 20kHz.
2 Hi mid gain/freq control knob This dual-concentric control knob adjusts
the gain/frequency of the hi mid EQ:
• gain The top control knob adjusts the gain of the hi mid band, which is
continuously variable from -15dB to +15dB with a centre detent of 0dB.
• freq The bottom control knob adjusts the centre frequency of the
hi mid band, which is continuously variable from 400Hz to 8kHz.
3 Hi mid width control knob This hi mid control knob adjusts the filter
bandwidth.
4 Lo mid width control knob This lo mid control knob adjusts the filter
bandwidth.
