Midas Venice F16 User Manual

89
VeniceF
Operator Manual
Output impedance All line outputs
Headphones
50 ohms balanced source
To drive 32 ohms
Maximum output level Line outputs (into 600R)
Headphones (into 50R)
+21dBu
+18dBu (750mW)
Digital output level Sampling frequency
Dynamic range (20Hz to
20kHz)
48kHz or 44.1kHz
105dB
Nominal signal level Mic
Line
-60dBu to +10dBu
0dBu
Equaliser mono channel Treble shelf
Treble frequency
Hi mid
Hi mid frequency
Hi mid bandwidth
Lo mid bandwidth
Lo mid
Lo mid frequency
Bass shelf
Bass frequency
15dB boost/cut
2kHz to 20kHz
15dB boost/cut
400Hz to 8kHz
0.1 to 2.0 Oct
0.1 to 2.0 Oct
15dB boost/cut
100Hz to 2kHz
15dB boost/cut
20Hz to 200Hz
Equaliser stereo channel Treble shelf
Hi mid bell
Lo mid bell
Bass shelf
15dB boost/cut control at
12kHz
15dB boost/cut control at
3kHz (1.4 Oct)
15dB boost/cut control at
300Hz (1.4 Oct)
15dB boost/cut control at
75Hz
