Mid-Continent Instruments and Avionics, Wichita, KS
REV. B, October 31, 2012 11 Manual Number 9017782
ARINC DATA LABELS
All labels are defined as Equipment ID 038 in BNR format.
High and Low speed options are configurable. See Section 3.4.
ARINC 429 Input Speed
Label Description High Low
203 altitude (rel 29.92) x x
204 baro altitude x x
ARINC 429 Output Speed
Label Description High Low
203 altitude (rel 29.92) x x
204 baro altitude x x
212 altitude rate x x
215 impact pressure x x
217 static pressure x x
324 pitch attitude x x
325 roll attitude x x
326 body pitch rate x
327 body roll rate x
330 body yaw rate x
331 body longitudinal acceleration x
332 body lateral acceleration x
333 body normal acceleration x
336 inertial pitch rate x
337 inertial roll rate x
340 inertial yaw rate x
364 vertical acceleration x
377 specific equipment id x x
TABLE 1.5
