REV. B, October 31, 2012 47 Manual Number 9017782
5.2 ENVIRONMENTAL QUALIFICATION STATEMENT
NOMENCLATURE: 2-inch Standby Attitude Module
MODEL NUMBER: MD302 Series PART NUMBER: 6420302-( )
TSO NUMBERS: C2d (Type B), C3e, C4c, C10b, C106, C113a, C179a
MANUFACTURERS SPECIFICATIONS:
Minimum Performance Specifications:TS302 (XX/XX/XX), TDS302 (XX/XX/XX)
Qualification Test Reports: QTR1201 (10/04/05)
MANUFACTURER: Mid-Continent Instrument Co., Inc.
ADDRESS: 9400 E. 34
th
St. North, Wichita, KS 67226, USA
RTCA DO-160: Rev G, dtd 12/08/10 DATES TESTED:06/12-09/12
CONDITIONS SECTION DESCRIPTION OF TEST
Temperature and Altitude
Low Temperature
High Temperature
Decompression
Overpressure
4
4.5.1
4.5.2
4.6.2
4.6.3
Category F1
Short and Normal Operating Low Temp = -30C
Short and Normal Operating High Temp = +70C
Altitude = 55K
-15,000 ft
Temperature Variation 5 Category S2
Humidity 6 Category A
Operational Shock and
Crash Safety
7 Category B
Vibration 8 Category R, Curves B, B1
(RBB1)
Explosion 9 Category X
Waterproofness 10 Category X
Fluids 11 Category X
Sand and Dust 12 Category X
Fungus 13 Category X
Salt Spray 14 Category X
Magnetic Effect 15 Category Z
Power Input 16 Category Z(XX)
Voltage Spike 17 Category A
Audio Frequency Conducted
Susceptibility
18 Category Z
Induced Signal Susceptibility 19 Category ZC
Radio Frequency Susceptibility 20
Category W (conducted)
Category F (radiated)
[WF]
Emission of Radio Freq Energy 21 Category P
Lightning Induced Transient
Susceptibility
22 Category B3 (pin injection)
Category H33 (cable bundle)
[B3H33]
Lightning Direct Effects 23 Category X
Icing 24 Category X
ESD 25 Category A
Fire, Flammability 26 Category X
REMARKS:
Sections 4: Category F1 complete with additional excursions as listed for Sections 4.5.1, 4.5.2, 4.6.2, and 4.6.3.
