Midcontinent MD302 Series User Manual

Mid-Continent Instruments and Avionics, Wichita, KS
REV. B, October 31, 2012 8 Manual Number 9017782
In Flight Mode, the unit operates normally by displaying attitude, altitude, airspeed and
slip information as shown in Figure 1.2.
Figure 1.2
FIGURE 1.2
roll/bank scale
pitch scale
symbolic airplane
slip indicator
barometer value
airspeed window
airspeed units
airspeed tape/scale
altitude trend bar
altitude window
altitude units
altitude tape/scale
