Middle Atlantic Products RM-KB-LCD17x8KVM User Manual

2. Hardware Setup
13
a) Screw the front flanges to the rack first.
b) Slide the bars with the rear flanges toward the rack until the flanges
make contact with the rack, then screw the rear flanges to the rack.
2. Slide the switch onto the support flanges. Use the bracket screws supplied
with this package to loosely attach the front of the switch to the front of the
rack (only tighten the screws part way).
HP 10-32 thread,
¾ inch
Phillips I head
M4L6
