RM-KB-LCD17x8/16KVM User Manual
14
3. Slide the rear attachment sliding brackets along the slide bars until they
contact the rear of the switch, then use the bracket screws supplied with
this package to attach the bars to the rear of the switch (tighten the screws
all the way).
4. Slide the switch open and closed a couple of times to be sure that it is
properly aligned and operating smoothly. (See p. 19 for opening and
closing procedures.)
5. After determining that the switch is properly lined up and operating
correctly, finish up by fully tightening down the partially tightened front
attached bracket screws inserted in step 2.
Phillips I head
M4L6
