Midea Aqua Tempo Super Series

Aqua Tempo Super Series air cooled scroll chiller unit (50Hz) MCAC-ATSM-201606
75
No.
Part Name
Qty
No.
Part Name
Qty
1
Condenser hoisting parts
1
13
The middle plate
2
1.1
Outlet net cover
2
14
Outdoor electric control box ass'y
1
1.2
Axial propeller
2
14.1
Welded parts of electric control box
1
1.3
Top cover ass'y
2
14.2
Outdoor main control board ass'y
1
1.4
Support ass'y of motor
2
14.3
Auxiliary plate ass'y of relay
1
1.5
Asynchronous motor
2
14.4
Outdoor main control board ass'y
1
1.6
Condenser sub-ass'y
2
14.5
Relay
2
1.7
Upper frame welded parts
1
14.6
AC contactor
1
1.8
Connection plate ass'y of condenser
2
14.7
Transformer
1
1.9
Water pan
2
14.8
Current transformer
1
1.10
Middle frame welded parts
1
14.9
Terminal block, 4P
1
2
Rear panel ass'y
2
14.10
Wire joint, 5p
1
3
Liquid accumulator
1
14.11
Terminal block
4
4
Column
4
14.12
Terminal block
1
5
Side panel ass'y
1
14.13
Capacitor
2
6
Inlet/outlet water pipe ass'y of plate heat exchanger
1
15
Water baffle
1
7
Holder ring
2
16
Front panel ass'y
1
8
Outlet water pipe ass'y of plate heat exchanger
1
17
Electrical box door
1
9
Parts of plate heat exchanger
1
18
Side panel ass'y
1
9.1
Welded part of fixed board,plate heat exchanger
1
19
Compressor(fixed)
1
9.2
Plate heat exchanger
1
20
Suction pipe ass'y
1
9.3
Differential pressure switch
1
20.1
Pressure controller
1
9.4
Connection pipe ass'y II of differential pressure valve
1
21
EXV ass'y
1
9.5
Connection pipe ass'y I of differential pressure valve
1
21.1
Electronic expansion valve
1
9.6
Outer joint
2
22
Sealplate
2
9.7
Connection water pipe ass'y
2
23
Pipe temp. sensor ass'y
1
10
Welded parts of base
1
24
Temperature controller of discharge pipe side
1
11
Gas-liquid separator
1
25
R410A
10
12
Four-way valve ass'y
1
26
Indoor temp. sensor ass'y T41
1
12.1
Four-way valve
1
27
Pipe temp. sensor ass'y
2
12.2
Pressure switch
1
28
Pipe temp. sensor ass'y
2
12.3
Pressure switch
1
29
Pressure sensor
1
12.4
Four-way valve coil
1
30
Pipe temp. sensor ass'y
1
