CCM-270A/WS Service Manual
2 First Time Installation Checklist
2.1 Flow Chart for CCM-270A/WS Touch Screen Centralized Controller
Below is a flow chart of the check points that need to be kept in mind while installing the CCM-270A/WS centralized
controller for first time.
Process
Check Point
Connect the IDU and ODU
with each other
Refer to the IDU and ODU respective installation manuals
Connect the power cable
to CCM-270A/WS
The power cable is not supplied with the CCM-270A/WS. The
user needs to purchase a power adaptor of 24VAC, current
1000mA
Auto Addressing & ENC4
Settings
The ODU needs to be set to auto addressing
1
Provide the power
It will take atleast one minute to reach the user login
interface from the boot screen
Login the CCM-270A/WS
The first login needs to be from administrator account,
Username: admin
Password: 1
Install the IDUs
Details discussed in 1.11 Login
Check Results
Details discussed in 1.12 Install the IDUs
Set Normal user account
An account with lesser permissions for the End User
Details discussed in 1.13 Checking the Installation Results
Connect the Power Meter
If the ECS function is required to be used, connect the power
meter. Details discussed in 1.15 Energy Meter Installation
1
The ENC4 settings are required to distinguish several ODUs from different system from each other, this setting is specially required when high end device like IMMPRO are being used.
