1 CCM-270A/WS
201807 45
Installation & Commissioning
2.2 Flow Chart for CCM-270A/WS Computer Website
Below is a flow chart of check points that need to be kept in mind while installing the CCM-270A/WS for computer
website.
Connect the IDU and ODU
with each other
Refer to the IDU and ODU respective installation manuals.
Connect the Power cable
to CCM-270A/WS
The power cable is not supplied with the CCM-270A/WS. The
user needs to purchase a power adaptor of 24VAC, current
1000mA himself.
If it is connected directly to the computer, it is simply
required to connect a LAN cable with computer.
Details discussed in 1.6 Network Connections.
Auto Addressing & ENC4
Settings
The ODU needs to be set to auto addressing.
1
It will take atleast one minute to reach the user login
interface from the boot screen.
The first login needs to be from administrator account,
Username: admin Password: 1
Install the IDUs & Check
results
Details discussed in 1.11 Login and 1.12 Install the IDUs.
An account with lesser permissions for the end user.
Details discussed in 1.13 Check the Installation Resuts
If the ECS function is required to be used, connect the power
meter. Details discussed in 1.15 Energy Meter Installation
1
The ENC4 settings are required to distinguish several ODUs from different system from each other.
To Next Page
