CCM-270A/WS

24 201807

CCM-270A/WS Service Manual

1.3 Flow Chart

Before we discuss in detail about the various steps that need to be followed for successful installation and commissioning

of CCM-270A/WS device, below is listed a flow chart of all the events that need to be followed. In this flow chart, is given a

sequence of actions that need to be followed to successfully finish the installation and commissioning of the

CCM-270A/WS gateway device both for touch screen and computer website.

1.3.1 For Touch Screen only

The following flow chart describes the installation steps while only the CCM-270A/WS is required to be used as a

centralized controller.

Connections between ODU &IDU

Power cable connection

Set the ODU to auto addressing mode and complete the

ENC4 switch settings

Set the normal user account

Install the energy meter and activate the ECS function

if the

ECS function is required to be used

Note: 1 The power cable is not provided as a standard accessory within the box. The user needs to buy the power cable from the market himself.

2 The LAN cable is also not an accessory in the box. The user needs to purchase it himself.

3. Refer to Functions Part 9.9ECS Settings for activation.
