DISASSEMBLY INSTRUCTIONS (CONT)
Procedure Illustration
3) Open the horizontal louver and push
the hook towards the left to open it.
4) Bend the horizontal louver lightly with
both hands to loosen the hooks, then
remove the horizontal louver.
Horizontal Louver
Hook
Hook
To Next Page
