DISASSEMBLY INSTRUCTIONS (CONT)
Procedure Illustration
5) Pry the electrical cover with a at
screw driver, and rotate it towards left,
then remove it.
6) Disconnect the display board connector.
7) Slide the front panel side to side to
release each axis.
