Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
43
DISASSEMBLY INSTRUCTIONS (CONT)
Procedure Illustration
8) Open the screw cap and then remove
the 3 screws.
9) Release the hooks by hand.
