Service manual for Dryer Machine Midea America Company
-------------------------------------------------------------------------------------------------------------------------------------------------------
－ 24 －
3.9 Door reversal
1. Unplug the power cord.
2. Remove the two hinge screws from the door.
3. Remove the door by lifting it.
4. Remove the cover-hinge.
5. Assemble the cover-hinge on the opposite side.
Use to remove cover-holder, cover-hinge with flat screw
driver.
6. Remove the 14 screws from the back cover back and
then remove the back cover and the door pin.
7. Remove the 8 screws from the inner door and
rotate the rest parts for 180 degrees.
8. Assemble the inner door and the back cover, place the
door pin on the opposite side and then fasten the 14 screws
that removed in step 6.
9. Install the door on the frame-front and then fasten the 4 screws
that removed in step 2.
