7. SPARE PART
ELECTRIC MODEL
No.
Part Name
Quantity
1
Door Subassembly
1.0
2
Door Hinge Cover
1.0
3
Cover Switch
1.0
4
Front Panel Assembly
1.0
5
Fixed Seat
2.0
6
Front Top Rail
1.0
7
Air Flue Assembly
1.0
8
Lint Filter Assembly
1.0
9
Front Support Assembly
1.0
12.1
Fixed Sheet Assembly
1.0
12.2
Impeller Assembly
1.0
12.3
Volute Assembly
1.0
12.4
Temperature Sensor
1.0
12.5
Thermostate
1.0
12.6
Single phase asynchronous motor
1.0
12.7
Clip Spring
2.0
12.8
Support For Tensioner Pulley Assembly
1.0
12.9
Safety Switch
1.0
12.10
Tapping screw
1.0
12.11
Spring
1.0
12.12
Motor Support
1.0
13
Base Subassembly
1.0
14
Rear Vent Pipe Assembly
1.0
15
Heater Support
1.0
16
Heater
1.0
17
Front Panel Pin
2.0
18
Side Plate
1.0
20
Hole Cover
1.0
21
Belt
1.0
22
Cabinet Cover Back
1.0
23
Basket Support Assembly
1.0
24
Air Flue Assembly
1.0
25
Internal Wire Assembly
1.0
26
Power Cord Cover
1.0
27
Basket Assembly
1.0
27.1
Felt
2.0
27.2
Lifter
3.0
