Service manual for Dryer Machine Midea America Company
-------------------------------------------------------------------------------------------------------------------------------------------------------
－ 11 －
3. Installation Instructions
3.1 Unit dimension
-The dryer should be located where there is enough space at the front for loading the dryer, and
enough space behind for the exhaust system.
-This dryer is factory-ready for the rear exhaust option. To exhaust out the bottom or left, use the
accessory exhaust kit. Instructions are included with the kit.
-Make sure the room in which the dryer is located has enough fresh air. The dryer must be located
where there are no air-flow obstructions.
-For gas dryers, adequate clearance must be maintained as noted on the data plate to ensure
adequate air for combustion and the proper dryer operation.
-The dryer must not be installed or stored in an area where it will be exposed to water and/or
weather. The dryer area must be kept clear of combustible materials, gasoline, and other
flammable vapors and liquids. A dryer produces combustible lint. The area around the dryer
should be kept lint-free.
Alcove or closet or wall insert/recessed installations
-The dryer must be exhausted to the outside to reduce the risk of fire when installed any place
inside the house.
-No other fuel-burning appliance should be installed in the same closet as the dryer.
Minimum clearances between the dryer and adjacent walls or other surfaces :
