6.Internal view and dimension
6.1Main parts and their names
(The picture is only for reference, and specific appearance and configuration are subject to the real
product)
Freezing chamber
Refrigerator chamber
1.Air duct front plate
2.Steel wire storage rack（big）
3.Air duct assembly of freezer
4.Steel wire storage rack（small）
5.Steel wire drawer
6.Leveling feet
7.Freezer door tray
8.Reversible adjustable shelf
9.Refrigerator door tray
6.2External dimension
Front view
Side view
