Service manual, 2016-12
22 / 42
Light of the refrigerating chamber is located upper
chamber
1） Remove the lamp cover
2） Remove the bulb
There is a light switch on the side wall of the
refrigerating chamber.
1） Loosen the hook with small normal screwdriver
and pull out the switch until the wire connector
reveals.
8.4Air duct and fan motor
Air duct components in freezing chamber
All accessories in the freezing chamber should be
dismantled before removing the air duct components.
1） Remove 2 screws on the cover plate of the freezing
air duct using a cross screwdriver;
2） Pull out the connector terminal of the fan motor;
To Next Page
