Midea UR-BD240WE-ST

Service Manual_2020-V1.0
16
5. Electric control system
5.1 Electrical parts parameters
Applicable Model
HS-312FWEN
Product Model
UR-BD240WE-ST
Product code
22031010001721
Rated Voltage
115V、60Hz
Item
Specification
Refrigerant
R600a
Compressor
EZ65H1Y
(Part code : 11101010006245)
Starting device type
Fixed Speed
The COP of compressor
1.95 (W/W)
The max cooling capacity of
compressor
117 W
Winding resistance of compressor
wiring terminal (20℃)
Rmc:6.83Ω±7%
Rsc:6.23Ω±7%
Rms = Rmc + Rsc
Winding resistance picture
Starter(PTC)
QP2-4R7
(Part code: 12031000001063)
Overload protector(OLP)
DRB26T61A1
(Part code : 12031000001317)
Integrate PTC+OLP
None
Variable frequency driver board
None
Capacitor
10.0μF、250V
Power filter (EMI)
None
Power reactor (EU EMC)
None
Motor
Fan motor of the freezing chamber
DC12V、4.0 W、1700r/min
Fan motor of the refrigerating
chamber
None
Electric damper
None
Lights
Lights inside the top of refrigerating
chamber
None
Lights inside the freezing chamber
None
Others Lights
None
