Service Manual_2020-V1.0
25
4）The reverse operation for assembly
Note: because the refrigerator without light, the switch
don’t control on and off
7.4 Air duct components in freezing chamber and fan motor
Air duct components in freezing chamber
All accessories in the freezing chamber should be
dismantled before removing the air duct components.
1)Remove 2 screws on the cover plate of the freezing
air duct using a cross screwdriver
2)Pull out the connector terminal of the fan motor;
3)Disassembly freezer air duct component
