Midea UR-BD240WE-ST - Evaporator and Defrost System

Service Manual_2020-V1.0
26
1） Remove the back of freezer air duct screw, break
the 11 buckles around and remove the front cover
2） Remove the 3 screws with a Phillips screwdriver to
separate the air duct cover and the fan
3） Change the fan motor, the reverse operation for
assembly
7.5 Evaporator and Defrost system
Evaporator in freezing chamber
