Midea WQP6-3603A User Manual

Lave vaisselle ELVC 491B
10
2. Unfit snap of heating pump assembly, and contrarotate heating pump assembly.
3. Reverse the above procedure to install. And check out all connectors connected well.
Part Name: 1
–
motor hunger
2
–
impeller assembly 3
–
pump seal ring
4 – lower pump 5 – motor assembly
Removal and Replacement
1. Take out heating pump motor assembly from the dishwasher machine. (see main heating
pump motor assembly removal and replacement)
2. Disassemble heating pump motor assembly. (see heating pump assembly removal and
replacement)
Motor
assembly
2
1
3
5
Screws
4

Midea WQP6-3603A Specifications

General

Brand	Midea
Model	WQP6-3603A
Category	Dishwasher
Language	English
