Lave vaisselle ELVC 491B
11
3. Take out two motor hungers, and remove screws for fixing impeller assembly and lower
pump to motor assembly.
4. Reverse the above procedure to install. And check out all connectors connected well.
Removal and Replacement
1. Remove cover of bottom board. (see main control board removal
and replacement)
2. Pull out all terminals of drain pump assembly.
3. Unfit snap of drain pump assembly, and contrarotate drain pump
assembly to take it out.
4. Reverse the above procedure to install. And check out all connectors connected well.
Removal and replacement
1. Remove cover of bottom board. (see main control board removal and
replacement)
2. Remove clamp fixing inner drain hose to bottom board, and pull it out .
To Next Page
