25. P-25 TEST MODE
Press SHIFT+ 0 to put the radio into test mode. Then press the following numbers
for the test you wish to perform.
1) Standard transmitter “Test Pattern”
2) Standard transmitter “Symbol Rate” pattern
3) Standard transmitter “Low Deviation” pattern
4) Standard transmitter “C4FM Modulation” Fidelity pattern
5) Standard “Tone Test”
- Sends the Standard Tone Test Pattern in TX mode.
- Indicates BER (Bit Error Rate) in RX mode.
Figure-42 Displays that the radio is in the “P25 Test Mode” and “Test Pattern”
Figure-43 Displays Symbol Rate
Figure-44 Displays Low Deviation
Figure-45 Displays C4FM Modulation
Figure-46 Displays TX Tone Test
Figure-47 Displays RX Tone Test and BER of 5%
<P25 Test Mode>
Test Pattern
C001 MD⌧N
Figure 42
<P25 Test Mode>
Symbol Rate
C001 MD⌧N
Figure 43
