8
www.midlandradio.com
Version 5.1
680-090-2042
7. P-25 CALLING SELECTION (Digital Base Mode Only)
Press and release A repeatedly to scroll through the menu
Radio displays GPC 00001= Group 1 Call, GPC everygroup= All Call,
IDC--------- = Individual Call
Figure-7 Shows Talk Group Identification (TGID), Group 1 Call
Figure-8 shows an All Call (everygroup), to everygroup on the same NAC
Figure-9 Shows an Individual Call, to and individual unit ID on the same NAC.
(Refer to Section 11, Figure 11 and 12 for ID entry).
RX
TX
C001 TAC 2 MDN
GPC 00001
Figure 7
RX
TX
C001 TAC 2 MDN
GPC everygroup
Figure 8
RX
TX
C001 TAC 2 MDN
IDC -------------------
Figure 9
