RXWH <Adjust>
TXW RX 0dbm Out
C001 25 / 31 MA
Figure 48
RXWH <Adjust>
TXW RX FX828 MOD1
C001 0 / 31 MA
Figure 49
RXWH <Adjust>
TXW DIGITAL DEVI
C001 27 / 31 MD
Figure 50
RXWS <Adjust>
TXW ANALOG DEVI
C001 19 / 31 MA
Figure 51
RXWH <Adjust>
TXW TONE DEVI
C001 27 / 31 MA
Figure 52
