GRX-3000
Midtronics bv. Lage Dijk-Noord 6 IJsselstein NL
www.midtronics.com
11
Chapter 2: Overview
GRX Battery Diagnostic Station: Front View
The controls to the GRX Battery Diagnostic Station are accessible on the front panel.
Chapter 2: Overview
Optional slide-in thermal printer
Allows you to print results after the charge cycle.
Status indicator lights
Lights in conjunction with beeping alarm to indicate
transitions and warnings
.
Expansion
plug-in module bay
Room for 5 expansion modules. Available are: Amp
clamp, DMM probes, Zigbee, WIFI, Bluetooth, Serial
connection, extra USB connection.
Display
Backlit graphical display and keypad for data entry.
Alphanumeric keypad
Keypad for data entry and selections in the various
menus.
