GRX-3000
Midtronics bv. Lage Dijk-Noord 6 IJsselstein NL
www.midtronics.com
12
Chapter 2: Overview
GRX Battery Diagnostic Station: Side View
On the right side of the unit you can nd an SD card slot and mini USB connection.
Data Card slot
Available for future software updates and data storage.
USB slot
Hardware prepared, functionality to be dened.
GRX Battery Diagnostic Station: Rear View
In addition to containing the outlet for the charger cables and power cord, the back of the unit is the location for the serial
number label and the ON/OFF switch.
Serial Number Label
The serial number of the unit.
ON/OFF switch
Switch the unit on or o.
AC Power cord
Connection for a grounded nominal 220 VAC outlet power cord. (2.4 meter in length)
Charger cable with Kelvin connection
Connection to the battery under charge.
Optional second charge channel
Optional channel for 24V Heavy Duty systems. With this second channel you can charge the 2 batteries in a 24V Heavy
Duty truck system simultaneously without disconnecting the batteries.
When this second channel is used both outputs receive 25A from the charger brick.
