Midtronics intellect EXP-1000 User Manual

• 23 •
Chapter 5: 5-Minute Discharged Battery Test
This test is an out-of-vehicle dynamic response test in which a deeply-discharged battery can be
diagnosed in minutes instead of the hours needed to charge it. The EXP displays the option to perform
the test after a deep scan and before it arrives at the battery decision. You can also perform a dynamic
response test during the in-vehicle System Test using the vehicle’s charging system to apply the
charging current.
The test requires an:
• External high-current charger
• Amp clamp
Test Routine
1. Have your amp clamp ready and select AMP CLAMP AVAILABLE.
1 AVAILABLE
2 NOT AVAILABLE
Press the NEXT soft key to continue.
2. Select charge current rate of the battery charger you will use for this test.
15 (10–60)
Press the NEXT soft key to continue.
3. Disconnect the analyzer’s clamps from the battery posts.
4. Make sure the charger’s power cord is disconnected and the power switch in the OFF
position.
5. Connect the charger’s clamps to the battery posts: red lead to the positive (+) terminal,
black lead to the negative (–) terminal.
6. Reconnect the analyzer’s clamps to the battery posts. Rock them back and forth so they
make good contact.
7. Connect the amp clamp to the EXP, and remove the clamp from any cables or wires.
8. Press the NEXT soft key to zero out the clamp.
9. Place the amp clamp around the negative (–) battery cable of the charger.
10. Plug in the charger’s power cord and turn on the charger.
Chapter 5: 5-Minute Discharged Battery Test
