Midtronics intellect EXP-1000 User Manual

• 39 •
DC AMP (requires the optional amp clamp)
The DC ammeter measures DC magnitude and ow of the DC current in a circuit.
1. Connect the amp clamp lead to the EXP’s accessories port.
2. Select the meter’s icon.
3. Select the amp clamp range.
1 70 AMP MAX.
2 700 AMP MAX.
Press the NEXT soft key to continue.
4. The meter will zero itself.
5. Place the clamp’s jaws around the negative (–) cable.
6. The EXP will display the measurement.
7. To return to the METERS menu, press the END soft key.
AC AMP (requires the optional amp clamp)
The DC ammeter measures the magnitude and ow of the AC current through a circuit during normal
operations.
1. Connect the amp clamp lead to the EXP’s accessories port.
2. Select the meter’s icon.
3. Select the amp clamp range.
1 70 AMP MAX.
2 700 AMP MAX.
Press the NEXT soft key to continue.
4. The meter will zero itself.
5. Place the clamp’s jaws around the negative (–) cable.
6. The EXP will display the measurement.
7. To return to the METERS menu, press the END soft key.
Chapter 9: Digital Multimeter
