Miele Connector Box - Electrical Connection

en - English
35
 Disconnect the Miele Professional ma-
chine from the mains voltage.
 Attach the Connector Boxbox to the wall
using the 4screws (4x40) and plugs (S6)
provided. See Fig. in the “”chapter.
 Alternatively, the Connector Box box can
be attached to the wall using the adhesive
strips provided. See Fig. in the
“”chapter.
 Establish the connection between the
Connector Boxbox and the Miele Profes-
sional machine and the external hardware
(e.g.payment system).
When connecting external hardware
provided by other manufacturers, the cable
cross-section must not be less than
1.0mm
2
with a maximum cable length of
2.50m (98 ¹/₃").
Mounting the cable strain relief
The connection cables of external hardware
must be fastened to the Connector Boxbox
using cable glands and cable strain relief
fixtures. See Fig. in the “”chapter at
the end of these operating and installation
instructions.
 Remove the lid from the Connector
Boxbox (remove the 2screws).
 Remove one or more of the cable strain
relief fixturesa.
 Stand the Connector Boxbox on its nar-
row end so that the sealed connection
holes are at the top.
 Using a screwdriver, press out the round
indentation in the connection hole b.
Tip: Pierce through the groove round the
edge at several places using a screwdriver.
 Insert the counter nutc.
 Screw on the threaded fittingd.
Tip: Slide the screw cape over the end of
the connection cable for the external hard-
ware.
 Guide the connection cable through the
threaded fitting and into the Connector
Boxbox.
 Tighten the screw cap.
The screw cap provides protection against
moisture and dust.
 Secure the connection cable with the
strain relieff.
 Make the required connections for the ex-
ternal hardware in the Connector Boxbox.
 Close the lid on the Connector Boxbox
(screw in the 2screws).
Key for cable strain relief in Fig. in the
“”chapter
a Cable strain relief fixtures
b Connection hole
c Counter nut
d Threaded fitting
e Screw cap
f Cable strain relief with screws
Configuration
Once the Connector Box box has been in-
stalled, the settings for the external func-
tions have to be made on the corresponding
Miele Professional machine.
Follow the instructions provided in the op-
erating and installation instructions for the
Miele Professional machine.
To enable communication with external
hardware (payment system, dispensing unit,
etc.), settings/configurations need to be
made on the Miele Professional machine.
Electrical connection
The Connector Box box is supplied with
mains voltage by the Miele Professional ma-
chine.
The Connector Box box does not have an
additional On/Off switch.
