All electrical work should be by a
licensed electrician, in strict
accordance with national and local
safety regulations and standards.
^
Note to installer:
Please leave these instructions with
the consumer.
^
Power supply:
Please check the data plate for
verification of:
240 VAC, 60 Hz, 15A,
L1, L2, Ground.
Caution:
Disconnect the main power supply
before servicing. To reduce the risk
of electric shock, make sure that the
appliance is properly grounded after
installation.
WARNING : THIS APPLIANCE
MUST BE GROUNDED
For USA only
The appliance is provided with 3
terminal leads, 1 black wire (L1), 1 red
wire (L 2) and 1 green wire (GND)
which have to be connected to a
dedicated junction box. Connect the
black wire to L1, the red wire to L2 and
the green wire to GND.
ALSO SEE THE WIRING DIAGRAM
PROVIDED WITH THE APPLIANCE.
For CDN only
The appliance is provided with 3
terminal leads, 1 black wire (L1), 1 red
wire (L 2) and 1 green wire (GND)
which have to be connected to a
dedicated junction box. Connect the
black wire to L1, the red wire to L2 and
the green wire to GND.
All hot wires (black and red) have to be
fused individually before connecting
them to the main power supply leads.
Use 15 Amp fuses or circuit
breakers for appliances rated 240
VAC.
ALSO SEE THE WIRING DIAGRAM
PROVIDED WITH THE APPLIANCE.
Electrical connection
53
