Building-in dimensions
83
Installation in a base unit
When building the appliance into a base unit underneath a cooktop, please also
obser
ve the installation instructions for the cooktop as well as the building-in
depth required for the cooktop (see installation instruction manual for the cook‐
top).
a
Steam oven
b
Niche
c
Inlet for mains connection cable to the appliance
d
Recommended position for electrical socket. Important: Do not position direct‐
ly behind the appliance.
e
Mains connection cable, L = 2000 mm
* Glass front / ** Metal front
