Miele G600 - Connecting Strip - Removal; Plinth Area with Connecting Strip

Technical Information
G600 & G800 Electronic Dishwashers
5.6 Connecting Strip - Removal
Figure 5-6: Plinth area with Connecting Strip
1. Remove the Cover Plate (5.5).
1. Remove the Raised Head and Countersunk Screws (Figure 5-6 –
Item 1).
2. Remove components from the Connecting Strip.
4. Remove the Connecting Strip.
61
