Technical Information
G600 & G800 Electronic Dishwashers
1
3
2
1 – Seal
2 – Flow Through Heater
3
Tem
erature Limiters
Figure 5-20: Flow-Through Heater with Seal (Item 1).
5.22 Temperature Limiter - Replacement
1. Remove the Left Side Panel (5.3).
2. Disconnect the Temperature Limiter Electrical Connections.
3. Loosen the Clamp from the Temperature Limiter using a
screwdriver.
4. Fit a new Temperature Limiter in the same position and secure it
with the Retaining Clamp.
5. Ensure the Retaining Clamp is seated correctly.
6. Connect the Plug Contacts.
74
