Technical Information
G600 & G800 Electronic Dishwashers
5.7 Basket Support Rollers – Replacement
Figure 5-7: Basket Guide
Warning!
Do not attempt to pry the Basket Guides free with a screwdriver; this
will result in irreversible damage to the cabinet walls.
1. Slide out the Basket Guide (Figure 5-7 – Item 1), until the Clip,
between the Bolt on the cabinet wall and the Basket Guide is
visible.
Figure 5-8: Bolt and Retaining Clip
62
