Technical Information
G600 & G800 Electronic Dishwashers
5.48 Fixing Bracket – Removal
Service Tip
The Fixing Bracket is removed to access to the following
components:
Turbothermic Fan / PTC Release
On / Off Button
Door Handle / Lock Assembly
Electronic(s)
B
A
Figure 5-41: Removing the Fixing Bracket
Refer to figure 5-41.
1. Remove the Control Panel (5.46 or 5.47)
2. Remove one Screw from each side of the Door (A)
3. Support the Fixing Bracket; remove the upper Screw (B)
4. Carefully lower the Fixing Bracket away from the Door.
96
