Miele G600 - Control Valve - Removal; Temperature Sensor (NTC) - Removal

Technical Information
G600 & G800 Electronic Dishwashers
5.33 Control Valve (Y6) - Removal
1. Lay the dishwasher on it’s back.
2. Remove the Drip Tray (5.29).
3. Disconnect the Electrical Connection to the Valve.
4. Note position of all Hoses. Disconnect the Hose Connections.
5. Remove the Control Valve.
Warning!
To prevent the possibility of a flooding condition:
Ensure all hoses to the Control Valve get connected correctly and are
not crushed, kinked or stretched.
5.34 Temperature Sensor (NTC) - Removal
1. Remove as much water as possible from the Sump.
2. Disconnect the Plug Connection from the Temperature Sensor.
3. Pull the Sensor outward to remove from the Sump.
Service Tip
During re-installation the Seal should be positioned within the
Sump assembly before installing the Temperature Sensor.
83
