Miele PG 8582 - Technical Data

Technical data
151
Height with machine lid
Height without machine lid
835mm
820mm
Width
598mm
Depth
Depth with door open
598mm
1,200mm
Wash cabinet dimensions:
Height
Width
Depth of upper basket/lower basket
520mm
530mm
474mm/520mm
Weight (net)
74kg
Max. load capacity of open door
37kg
Voltage, rated load, fuse rating See data plate
Connection cable
Approx. 1.8m
Water connection temperature:
Cold water/steam condenser
Hot water/demineralised water
Max. 20°C
Max. 65°C
Static water pressure
Max. 1,000kPa pressure
Minimum water connection flow pressure:
Cold water/steam condenser
Hot water
Demineralised water
100kPa pressure
40kPa pressure
30kPa pressure
Recommended water connection flow pressure:
Cold water/hot water
Demineralised water
Steam condenser
≥200kPa pressure
≥200kPa pressure
≥100kPa pressure
Delivery head
Min. 0.3m, max. 1.0m
Drainage length
Max. 4.0m
Operation (according to IEC/EN 61010-1):
Ambient temperature
Relative humidity maximum
linear decrease to
Relative humidity minimum
5°C to 40°C
80% for temperatures up to 31°C
50% for temperatures up to 40°C
10%
Storage and transportation conditions:
Ambient temperature
Relative humidity
Air pressure
- 20°C to 60°C
10% to 85%
500hPa to 1060hPa
Altitude above sea level (according to IEC/EN 61010-1)
Up to 2,000m *
Protection category (according to IEC60529)
IP21
Soiling level (according to IEC/EN61010-1)
2
Overvoltage category (according to IEC60664)
II
Noise level in dB(A),
sound pressure LpA during cleaning and drying phases
<70
Test certifications VDE, EMC radio suppressed
marking MDD guidelines 93/42/EEC, Class IIb
Manufacturer address Miele & Cie. KG, Carl-Miele-Straße 29,
33332 Gütersloh, Germany
* If installation site is above 1,500m, the boiling point of the wash water will be lower. In this case, the disinfecting temperature
and the holding time will need to be reset by the Miele Customer Service Department.
