Miele WTF 130 WPM User Manual

Before using for the first time
19
 Before using the washer-dryer
for the first time ensure that it is cor-
rectly installed and connected. See
"Installation and connection". Also
check that the drain filter is securely
tightened to prevent the risk of water
leaks during use.
This washer-dryer has undergone a
complete functional test at the factory
and there will be some residual water
in the drum from this process.
Switch the washer-dryer on
 Press the  button.
The welcome screen will light up.
Select the language
You will be asked to select the language
you want for the display. It is possible
to change the language at any time via
"Settings".
deutsch 
 Touch the  or  sensor until the
language you want appears in the
display.
 Confirm your selection of the lan-
guage by touching the OK sensor.
Miele@home
The display indicates that this washer-
dryer can be connected to the
Miele@home system via a communica-
tion module (only available in selected
countries).
 Confirm the message in the dispaly
with OK.
Remove the transit bars
A reminder to remove the transit bars
will appear in the display.
 Failure to remove the transit bars
can result in damage to the washer-
dryer and to adjacent cabinetry or
appliances.
Remove the transit bars as described
in "Installation and connection".
 After removing the transit bars (if this
has not already been done by your
fitter) confirm by pressing the OK but-
ton.

Miele WTF 130 WPM Specifications

General

Door hinge	Right
Control type	Buttons, Rotary
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Half-load	-
Drying capacity	4 kg
Washing capacity	7 kg
Delay start (max)	24 h
Spin-drying class	A
Maximum spin speed	1600 RPM
Noise level (wash)	- dB
Water consumption washing per cycle	90 L
Energy consumption washing per cycle	- kWh
Water consumption washing & drying per cycle	- L

Weight and Dimensions

Depth	636 mm
Width	596 mm
Height	850 mm
