MM660 Installation Instructions 20
10’
Max
1
2
W
W
Control Box Installation
Receiver Installation
NOTE: Once you have completed the installation, you may need to relocate the receiver to get
better reception distance.
Consider the following when mounting the receiver:
• Standard receiver cable length is 10 feet (receivers with a longer cable are available as special
order items; call the Mighty Mule Sales Department). NEVER splice receiver cable!
• Run the cable through PVC conduit to protect it from damage.
• DO NOT run cable through metal conduit because the receiver signal range will be decreased.
• DO NOT run cable through conduit containing AC wire.
• DO NOT place receiver within 3 feet of AC power.
• DO NOT coil excess cable or store it in the control box.
• Do not mount upside down.
• The receiver range can vary from 50 to 100 feet depending upon weather, topography, and
external interference.
