Mikado LOGO 200 - Main Frame Assembly Steps; 1.1 Main Frame - Motor Mounting; Top Bearing Block

1.1 Main Frame - Motor Mounting / Top Bearing Block
Manual Logo 200 - ©Mikado Model Helicopters - Page 4
3 x
2 x
4 x
1 x
M2.5x7
M1.6 x 4
M3x2.5
M1.6 x 6
M1.6x4
M1.6x6
M3x2.5
4x9x4 bearing
M2.5x7
1
2
1 x
4x9x4 bearing
