1.5 Main Frame - Landing Gear Mounting
4 x
2 x
8 x
M1.6 x 4
M1.6 x 3
M2x4
4 x
M2 sleeve
Manual Logo 200 - ©Mikado Model Helicopters - Page 7
M1.6X4
M2x4
M2x4
M2 sleeve
M2 sleeve
M1.6x3
M1.6x3
M1.6X3
