4.4 Switch Group 4
This switch group configures the operation characteristic of relay output "TRIP,
(TS2)".
T2OLT2OL - TS2 Low-set Overcurrent Trip
This switch is permanently set to '1' and not user selectable. The low-set
overcurrent trip signal is always linked to the relay output TRIP.
T2OH T2OH - TS2 High-set Overcurrent Trip
This switch is permanently set to '1' and not user selectable. The high-set
overcurrent trip signal is always linked to the relay output TRIP.
T2EL T2EL - TS2 Low-set Earth-Fault Trip
This switch is permanently set to '1' and not user selectable. The low-set
earth-fault trip signal is always linked to the relay output TRIP.
T2EH T2EH - TS2 High-set Earth-Fault Trip
This switch is permanently set to '1' and not user selectable. The high-set
earth-fault trip signal is always linked to the relay output TRIP.
REMOTEREMOTE ELATCHELATCH ILATCHILATCH CBFPCBFP T2EHT2EH T2ELT2EL T2OHT2OH T2OLT2OL
Default value
0 0 0 0 1 1 1 1
Default hexa-
decimal value
0 F
User setting
1 1 1 1
User hexadeci-
mal value*
F
* Refer to Appendix A for the corresponding hexadecimal value.
MK2000
Page 23
