T1EH T1EH - TS1 High-set Earth-Fault Trip
This switch selects or de-selects the linkage between the high-set earth-
fault trip signal and the relay output START1 (TS1).
1 = I
O
>> trip signal linked to TS1.
0 = I
O
>> trip signal not linked to TS1.
ST1OLST1OL - TS1 Low-set Overcurrent Start
This switch selects or de-selects the linkage between the low-set
overcurrent start signal and the relay output START1 (TS1).
1 = I> start signal linked to TS1.
0 = I> start signal not linked to TS1.
ST1OHST1OH - TS1 High-set Overcurrent Start
This switch selects or de-selects the linkage between the high-set
overcurrent start signal and the relay output START1 (TS1).
1 = I>> start signal linked to TS1.
0 = I>> start signal not linked to TS1.
ST1ELST1EL - TS1 Low-set Earth-Fault Start
This switch selects or de-selects the linkage between the low-set earth-
fault start signal and the relay output START1 (TS1).
1 = I
O
> start signal linked to TS1.
0 = I
O
> start signal not linked to TS1.
ST1EH ST1EH - TS1 High-set Earth-Fault Start
This switch selects or de-selects the linkage between the high-set earth-
fault start signal and the relay output START1 (TS1).
1 = I
O
>> start signal linked to TS1.
0 = I
O
>> start signal not linked to TS1.
MIKRO
Page 22
