4.3 Switch Group 3
This switch group configures the operation characteristic of relay output
"START1, (TS1)".
T1OLT1OL - TS1 Low-set Overcurrent Trip
This switch selects or de-selects the linkage between the low-set overcurrent
trip signal and the relay output START1 (TS1).
1 = I> trip signal linked to TS1.
0 = I> trip signal not linked to TS1.
T1OHT1OH - TS1 High-set Overcurrent Trip
This switch selects or de-selects the linkage between the high-set
overcurrent trip signal and the relay output START1 (TS1).
1 = I>> trip signal linked to TS1.
0 = I>> trip signal not linked to TS1.
T1ELT1EL - TS1 Low-set Earth-Fault Trip
This switch selects or de-selects the linkage between the low-set earth-fault
trip signal and the relay output START1 (TS1).
1 = I
O
> trip signal linked to TS1.
0 = I
O
> trip signal not linked to TS1.
ST1EHST1EH ST1ELST1EL ST1OHST1OH ST1OLST1OL T1EHT1EH T1ELT1EL T1OHT1OH T1OLT1OL
Default value
0 0 0 0 0 0 0 0
Default hexa-
decimal value
0 0
User setting
User hexadeci-
mal value*
* Refer to Appendix A for the corresponding hexadecimal value.
MK2000
Page 21
