HOESHOES - High-set Overcurrent Element Select
This switch activates or de-activates the high-set overcurrent function. The
I>> will not operate once de-activated.
1 = High-set overcurrent (I>>) function de-activated
0 = High-set overcurrent (I>>) function activated.
HEESHEES - High-set Earth-fault Element Select
This switch activates or de-activates the high-set earth-fault function. The
Io>> will not operate once de-activated.
1 = High-set earth-fault (Io>>) function de-activated.
0 = High-set earth-fault (Io>>) function activated.
RSVRSV - Reserve
These switches are always set to '0'. They are reserved for future use.
MIKRO
Page 20
