Milesight EM400-MUD - Uplink Data

19
6.1.1 Uplink Data
Channel
Type
Description
ff
01(Protocol Version)
01=>V1
09 (Hardware Version)
01 40 => V1.4
0a (Software Version)
01 14 => V1.14
0b (Power On)
Device is on
0f (Device Type)
00: Class A, 01: Class B, 02: Class C
16 (Device SN)
16 digits
01
75(Battery Level)
UINT8, Unit: %
03
67 (Temperature)
INT16, Unit: °C
04
82 (Distance)
INT16, Unit: mm
05
00 (Device Position)
00: Normal (horizontal offset angle < 20°)
01: Tilt (horizontal offset angle ≥ 20°)
83
67(Temperature)
Temperature (2 Bytes) + Alarm Status(1
Byte)
Temperature: unit -- °C
Alarm Status:
00 -Alarm dismiss
01 -Alarm
84
82(Distance)
Distance (2 Bytes) + Alarm Status (1 Byte)
Distance: unit -- mm
Alarm Status:
00 -Alarm dismiss
01 -Alarm
Examples:
1. Device information: report once whenever join the network.
ff0bff ff0101 ff166329c42503920003 ff090100 ff0a0101 ff0f00
Channel
Type
Value
Channel
Type
Value
ff
0b
(Power On)
ff
(Reserved)
ff
01
(Protocol Version)
01 (V1)
Channel
Type
Value
Channel
Type
Value
ff
16
(Device SN)
6329c425
03920003
ff
09
(Hardware version)
0100
(V1.0)
Channel
Type
Value
Channel
Type
Value
ff
0a(Software
version)
0101
(V1.1)
ff
0f
(Device Type)
00
(Class A)
