Milesight EM400-MUD - Page 23

23
Start
ID
Packet
Length
FLAG
Frame
Counter
Protocol
Version
Software
Version
Hardware
Version
02
0001
2 Bytes
00
0000
01
4 Bytes
4 Bytes
SN
IMEI
IMSI
ICCID
Signal
Data Length
Data1
...
16
Bytes
15
Bytes
15
Bytes
20
Bytes
1 Byte
2 Bytes
N Bytes
...
Example:
02 0001 005f 00 0000 01 30313031 30313030
36373438443131323930313230303033 383638353038303631393234353133
343630303833383833383036363836
3839383630346238313032326330343536363836 10 000E
01750103677D000482FDFF050000
Type
Content
Start
02
ID
0001
Packet Length
00 5f=95 bytes
FLAG
00
Frame Counter
0000
Protocol Version
01=V1
Software Version
30 31 30 31 => 0101=V1.1
Hardware Version
30 31 30 30 => 0100=V1.0
SN
36 37 34 38 44 31 31 32 39 30 31 32 30 30 30
33=>6748d11290120003
IMEI
38 36 38 35 30 38 30 36 31 39 32 34 35 31 33
=>868508061924513
IMSI
34 36 30 30 38 33 38 38 33 38 30 36 36 38 36 =>
460083883806686
ICCID
38 39 38 36 30 34 62 38 31 30 32 32 63 30 34 35 36 36
38 36 => 898604b81022c0456686
Network Signal
10=>16 asu
Data Length
0e=>14 Bytes
Data
See details below
Data part is based on Channel+Type+Data, the Data field should follow little-endian:
Channel
Type
Description
01
75(Battery Level)
UINT8, Unit: %
03
67 (Temperature)
INT16, Unit: °C
04
82 (Distance)
INT16, Unit: mm
05
00 (Device Position)
00: Normal (horizontal offset angle < 20°)
01: Tilt (horizontal offset angle ≥ 20°)
